Chapter 12: Python Applications

Notes

Advanced Functions

  • Python functions are powerful and can be used in some interesting ways

References to Functions

  • We’ve seen that we can use references to functions much like variables

  • e.g. map in Chapter 10 took a reference to a function and applied it element-wise to a list

  • Let’s explore this in more detail, consider the following code snippet (see SimpleFunctionReferences.py)

      # Example 12.1 Simple Function References

      def func_1():
          print("Hello from function 1")

      def func_2():
          print("Hello from function 2")

      x = func_1
      x()
      x = func_2
      x()
    Hello from function 1
    Hello from function 2
  • We have two functions func_1 and func_2

  • We can assign the variable x to refer to and call each of these in turn

    • The dereference operator () called on x resolves to the function it references
  • The variable is effectively another name for the function

  • We still have to call it properly, e.g. (see InvalidFunctionReferences.py)

      # Example 12.2 Invalid Function References

      def func_1():
          print("Hello from func_1")

      x = func_1
      x(99)
    ---------------------------------------------------------------------------
    TypeError                                 Traceback (most recent call last)
    Cell In[2], line 7
          4     print("Hello from func_1")
          6 x = func_1
    ----> 7 x(99)

    TypeError: func_1() takes 0 positional arguments but 1 was given
  • The above generates an error as expected, because x is given an argument 99

  • func_1 takes no arguments

  • The error resolves to the original function name (here func_1)

Use Function References in the BTCInput Module
  • Recall back in Chapter 7 we created a module for getting validated user input, BTCInput

  • We wrote code for reading integers and floating points with an additional ranged API

  • Both functions pretty much looked the same except one used int() to convert user input, the other used float()

  • As a refresher here is read_int

      def read_int(prompt):
          while True:
              try:
                  # read in the number
                  number_text = read_text(prompt)
                  # perform conversion to int
                  result = int(number_text)
                  break
              except ValueError:
                  print("Please enter an integer")
          return result
  • We could combine these two functions into one by using a function-valued variable

  • i.e. the function now accepts as a argument a function that takes in a string and converts the result to the appropriate type of number

      def read_number(prompt, number_converter):
          """
          Read and convert a user-provided number

          User is prompted for a number, and the resulting
          string is converted by the supplied `number_converter`
          function

          Parameters
          ----------
          prompt : str
              string to display to the user when asking for input
          number_converter : Callable[[[str], int | float]
              function that converts a string to a number. Must
              raise a `ValueError` on invalid input

          Returns
          -------
          int | float
              User input converted to a number
          """
          while True:
              try:
                  number_text = read_text(prompt)
                  result = number_converter(number_text)
                  break
              except ValueError:
                  print("Please enter a number")
          return result
  • Now the call to int or float is instead replaced with a call to number_converter

  • As part of the documentation we have to specify the required behaviour of the number_converter function

    • Here we need it to be a one parameter function that accepts a string
    • The returned result should be an int or float
    • Additionally a key requirement is that any failed conversion raises a ValueError so that the error-handling code in read_number catches it
  • read_number is a great function from our programmer perspective

    • But not necessarily the cleanest implementation for a downstream user
    • They would still likely just want to call read_int or read_float
    • We’ll provide wrapper functions read_int and read_float that pass the appropriate parameters through to read_number
      • We’ll make them match the old API for input so a downstream user sees no change
      def read_float(prompt):
          return read_number(prompt=prompt, number_converter=float)
  • Observe when we pass a function we just pass the name, don’t use ()

Code Analysis: Function References

Function references are complicated, work through the following questions to help your understanding

  1. What is a function reference?

    • One piece of a program telling another what to do
    • read_number is given a prompt, and a function
      • The function tells read_number how to convert to a number
  2. Why is using function references like this a good idea?

    • Makes code more maintainable
    • Rather than having basically the same code in two places read_int and read_float we have it in one place
    • If we later need to modify the code, we can now do it in one place read_number rather than making sure both functions remain consistent
  3. If I wrote a function that converted Roman numerals into a numeric result, could I use read_number to read Roman Numbers?

    • Yes, as long as that function matches the requirements for number_converter

    • i.e. Only takes in a string

      • Easy enough, this should be the roman numerals
    • Returns either an int or float

      • Easy again Roman numerals convert to integers
    • Raises a ValueError if an invalid Roman numeral is encountered

    • If we meet this API we could then use read_number e.g.

        number = read_number("Enter your age in roman numerals: ", number_converter=roman_converter)
    • There is in fact nothing (other than the name read_number) that prevents us from using this function more generally

    • We could let number_converter be any function that takes a string argument, and returns a value, raising a ValueError on invalid input

      • e.g. we could write date_converter that asks the user for a valid date string (e.g. 12/10/2017)
      • Could convert this into a date object
    • Function parameters are thus a form of abstraction

      • We step away from a more concrete implementation (read_int, read_float etc)
      • Use a more general solution read_number
      • We may then find that our solution is more general then we thought
        • e.g. read_number actually provides a structure to parse a lot of input depending on the provided parsing function (number_converter)
        • i.e. we might instead call read_number as parse_input
Exercise: Write a Roman Numeral Converter

Write a function that takes a string representing roman numerals and converts it to an integer. Make this function work with the read_number API

First lets set out some ground rules. The valid roman numerals are:

Symbol I V X L C D M
Value 1 5 10 50 100 500 1000

The standard form for the roman numerals is given by,

Thousands Hundreds Tens Ones
1 M C X I
2 MM CC XX II
3 MMM CCC XXX III
4 CD XL IV
5 D L V
6 DC LX VI
7 DCC LXX VII
8 DCCC LXXX VIII
9 CM XC IX

To create a value we append the appropriate thousands, hundreds, tens, and ones.

e.g. \(3698 = MMM + DC + XC + VIII = MMMDCXCVIII\)

The basic conversion rules are as follows,

  1. Read from left to right

  2. Consider a “digit”.

    • If the next digit is the same value or less, then it is added to the total
      • e.g. in \(II\) and \(XI\), we read these as \(1 = 1\), and \(10 > 1\), so the running total is \(1\) and \(10\) respectively
    • If the next digit is a greater value, then we subtract from the total
      • e.g. in \(IV\) we read this as \(1 < 4\), so the running total is \(-1\)
    • If there is no next digit, then the value is added

This is the basic ruleset, we could write a function to convert using these rules and be perfectly happy with it. However, in many modern use cases there are stricter syntax rules which for fun we’ll also implement, namely

  1. \(M\), \(C\), \(X\), \(I\) can be repeated no more than three times sequentially, e.g. \(IIII\) is invalid
  2. \(V\), \(L\), \(D\) can’t be sequentially repeated, e.g. \(VV\) is invalid
  3. There can be no repeated sequence of the same value before a subtraction, i.e. \(IIV\) is invalid because this should translate to \(5 - 2\).
  4. There are precedence rules
    • “Tens”-like values can only precede smaller or the next two largest valued characters
      • e.g. \(IV\) or \(IX\) are valid, but not \(IM\)
      • e.g. \(XL\) or \(XC\) are valid, but not \(XD\)
    • “Fives”-like can values can only precede smaller
      • e.g. \(VI\) is valid, but not \(VX\)
      • e.g. \(LI\) and \(LX\) are valid, but not \(LD\)

Let’s now plan out our algorithm, before considering valid syntax the basic structure will be as follows,

  1. set a running total to \(0\)

  2. Iterate over each character

    1. Convert the character to their integer value
    2. If the next character exists and it’s value is larger subtract the current value from the total
    3. Else, add the current value
  3. Once all the characters have been processed return the total

The easiest way to do this would be to use a dictionary lookup. We can directly convert the symbol to a value. Now let’s go one step further. We’ll define a lightweight class RomanNumeral this holds the symbol, the value and importantly also a set bookkeeping what other roman numerals this one is allowed to precede

class RomanNumeral:
    """
    Lightweight class representing a roman numeral

    Attributes
    ----------
    symbol : str
        latin character symbolising the roman numeral
    value : int
        numeric value of a roman numeral
    precedes : set[str]
        set of strings representing other roman numerals this numeral may precede
    """

    def __init__(self, symbol, value, precedes):
        """
        Create a new `RomanNumeral` Instance

        Parameters
        ----------
        symbol : str
            latin character symbolising the roman numeral
        value : int
            numeric value of a roman numeral
        repetition_limit : int
            maximum number of times the same numeral can be repeated
        precedes : set[str]
            set of strings representing other roman numerals this numeral may precede
        """
        self.symbol = symbol
        self.value = value
        self.precedes = precedes

    def may_precede(self, roman_numeral):
        """
        Checks if this numeral may precede another

        Parameters
        ----------
        roman_numeral : str
            character representing roman numeral to check if we can precede

        Returns
        -------
        `True` if `self` may precede `roman_numeral` else, `False`
        """
        return roman_numeral in self.precedes
  • We define one helper function may_precede which is used to check if one symbol may precede another
  • We then define at the start of our function a dictionary containing the valid roman numerals
def roman_numeral_converter(number_string):
    """
    Convert a number written in roman numerals to an int

    The string must be a valid roman numeral in `standard format`__

    Parameters
    ----------
    number_string : str
        A valid roman numeral expression

    Returns
    -------
    int
        Result of converting the roman numeral to an int

    Raises
    ------
    ValueError
        Raised if `number_string` is not a valid roman numeral

    .. _standard format: https://en.wikipedia.org/wiki/Roman_numerals#Standard_form
    """
    roman_numerals = {
        "I": RomanNumeral("I", 1, {"I", "V", "X"}),
        "V": RomanNumeral("V", 5, {"I"}),
        "X": RomanNumeral("X", 10, {"I", "X", "L", "C"}),
        "L": RomanNumeral("L", 50, {"I", "V", "X"}),
        "C": RomanNumeral("C", 100, {"I", "V", "X", "L", "C", "M"}),
        "D": RomanNumeral("D", 500, {"C", "L", "X", "V", "I"}),
        "M": RomanNumeral("M", 1000, {"I", "V", "X", "L", "C", "D", "M"}),
    }

    def get_roman_numeral(numeral):
        """
        Returns the `RomanNumeral` corresponding to the provided string

        Parameters
        ----------
        numeral : str
            character representing a roman numeral digit

        Returns
        -------
        RomanNumeral
            object describing the corresponding roman numeral

        Raises
        ------
        ValueError
            The provided character is not a valid roman numeral digit

        """
        try:
            return roman_numerals[numeral]
        except KeyError:
            raise ValueError(numeral, "is not a valid character for a roman numeral")
  • The function get_roman_numeral is a helper function defined inside our converter
    • It wraps the error handling of getting the roman numeral from the dictionary
    • It’s main purpose is to convert a KeyError for an invalid character into a ValueError as required by the read_number interface
  • Now lets work through our previous algorithm and add in the syntax checking at the appropriate steps
  1. set a running total to \(0\), and previous to None

  2. Iterate over each character

    1. If the character doesn’t exist, a ValueError is raised
    2. If this character is the same as the previous increment the number of repetitions
      • If it’s more than three, raise a ValueError for violation of the repetition rule
      • Else reset the number of repetitions
    3. Check if we’re at the end of the string
      • If so, add the current character’s value to the total and return
      • Else, attempt to get the next character’s roman numeral data
        • Again raise a ValueError if it doesn’t exist
    4. Check that the current character is allowed to precede the next character
      • Raise a ValueError if it can’t
    5. Check the next character’s value is larger
      • If it is
        • Check if the number of repetitions is greater than \(1\)
          • If it is, raise a ValueError since there can be no repetitions before a subtraction
          • Else subtract the value of the current character from the total
      • Else
        • Add the value to the current total
    6. Set the previous to the current character

The complete implementation is given by,

def roman_numeral_converter(number_string):
    """
    Convert a number written in roman numerals to an int

    The string must be a valid roman numeral in `standard format`__

    Parameters
    ----------
    number_string : str
        A valid roman numeral expression

    Returns
    -------
    int
        Result of converting the roman numeral to an int

    Raises
    ------
    ValueError
        Raised if `number_string` is not a valid roman numeral

    .. _standard format: https://en.wikipedia.org/wiki/Roman_numerals#Standard_form
    """
    roman_numerals = {
        "I": RomanNumeral("I", 1, {"I", "V", "X"}),
        "V": RomanNumeral("V", 5, {"I"}),
        "X": RomanNumeral("X", 10, {"I", "X", "L", "C"}),
        "L": RomanNumeral("L", 50, {"I", "V", "X"}),
        "C": RomanNumeral("C", 100, {"I", "V", "X", "L", "C", "M"}),
        "D": RomanNumeral("D", 500, {"C", "L", "X", "V", "I"}),
        "M": RomanNumeral("M", 1000, {"I", "V", "X", "L", "C", "D", "M"}),
    }

    def get_roman_numeral(numeral):
        """
        Returns the `RomanNumeral` corresponding to the provided string

        Parameters
        ----------
        numeral : str
            character representing a roman numeral digit

        Returns
        -------
        RomanNumeral
            object describing the corresponding roman numeral

        Raises
        ------
        ValueError
            The provided character is not a valid roman numeral digit

        """
        try:
            return roman_numerals[numeral]
        except KeyError:
            raise ValueError(numeral, "is not a valid character for a roman numeral")

    total = 0
    previous = None
    n_reps = 0
    number_string = number_string.upper().strip()
    max_repeats = 3

    for i, ch in enumerate(number_string):
        # get the roman numeral associated with the next character
        numeral = get_roman_numeral(ch)
        if numeral.value == previous:
            # check that we haven't repeated this numeral too many times
            n_reps += 1
            if n_reps > max_repeats:
                raise ValueError(
                    ch,
                    "repeated {0} times, maximum is {1}".format(n_reps, max_repeats),
                )
        else:
            n_reps = 1
        if i + 1 == len(number_string):  # reached the end and stop
            return total + numeral.value
        else:
            next_numeral = get_roman_numeral(number_string[i + 1])

            if not numeral.may_precede(next_numeral.symbol):
                raise ValueError(
                    "Invalid roman numeral: {0} may not precede {1}".format(
                        numeral.symbol, next_numeral.symbol
                    )
                )
            # if next is larger perform subtraction if valid
            if next_numeral.value > numeral.value:
                if n_reps > 1:
                    raise ValueError(
                        "Invalid roman numeral: cannot repeat digits for subtraction"
                    )
                else:
                    total -= numeral.value
            else:
                total += numeral.value
        previous = numeral.value
    return total

Which we can see on some sample valid inputs,

print("I: Expected: 1, Received: {0}".format(roman_numeral_converter("I")))
print("V: Expected: 5, Received: {0}".format(roman_numeral_converter("V")))
print("X: Expected: 10, Received: {0}".format(roman_numeral_converter("X")))
print("II: Expected: 2, Received: {0}".format(roman_numeral_converter("II")))
print("III: Expected: 3, Received: {0}".format(roman_numeral_converter("III")))
print(
    "MMMDCXCVIII: Expected: 3698, Result: {0}".format(
        roman_numeral_converter("MMMDCXCVIII")
    )
)
I: Expected: 1, Received: 1
V: Expected: 5, Received: 5
X: Expected: 10, Received: 10
II: Expected: 2, Received: 2
III: Expected: 3, Received: 3
MMMDCXCVIII: Expected: 3698, Result: 3698

And on a sample invalid input,

    print(
        "VV: Expected: Invalid Number, Received: {0}".format(
            roman_numeral_converter("VV")
        )
    )
---------------------------------------------------------------------------
ValueError                                Traceback (most recent call last)
Cell In[6], line 3
      1 print(
      2     "VV: Expected: Invalid Number, Received: {0}".format(
----> 3         roman_numeral_converter("VV")
      4     )
      5 )

Cell In[4], line 84, in roman_numeral_converter(number_string)
     81 next_numeral = get_roman_numeral(number_string[i + 1])
     83 if not numeral.may_precede(next_numeral.symbol):
---> 84     raise ValueError(
     85         "Invalid roman numeral: {0} may not precede {1}".format(
     86             numeral.symbol, next_numeral.symbol
     87         )
     88     )
     89 # if next is larger perform subtraction if valid
     90 if next_numeral.value > numeral.value:

ValueError: Invalid roman numeral: V may not precede V

A more comprehensive set of tests can be found in the complete program

Note

Trusting vs Checking the Input

You can see that compared to the simple algorithm outlined for the case were we assumed the input was valid, the final algorithm is a lot longer. This is most due to it performing syntax validation at the same time as it calculates the result.

This is a common philosophical argument. Should roman_numeral_converter validate it’s input. In principle we could write a function validate_roman_numeral which would check that the string is valid. Doing it this way means we could make roman_numeral_converter itself quite lean. This has the downside that we would need to make two passes through the string now. The first to validate and the second to convert it.

There are two sides here, the safer version of roman_numeral_converter can be used anywhere and always ensures it’s input is valid. This comes at the cost that for valid input we are doing extra work checking it. Thus it’s a tradeoff, if we expect to receive valid input then we can use the fast version (and if there is perhaps a separate path that can supply invalid input we might use validate_roman_numeral), but if not we should use a protected version.

Since our implementation is designed to be for parsing user input, I’ve combined the code into one function. In the future if the design requirements changed I might revisit this choice

There’s another more simple implementation of this. If we restrict ourselves as above to the standard form then we can only represent \(1\) to \(3999\), and each has a unique representation. Thus we could create an explicit conversion dictionary that makes the string representation to the integer representation. This is a form of lookup table. We set the lookup table to be generated when the roman numeral conversion code is loaded.

# Exercise 12.1b Roman Numeral Converter
#
# Write a function that converts strings of roman numerals to an integer
#
# This implementation uses a lookup table

import itertools

import BTCInput

thousands = {"": 0, "M": 1000, "MM": 2000, "MMM": 3000}
hundreds = {
    "": 0,
    "C": 100,
    "CC": 200,
    "CCC": 300,
    "CD": 400,
    "D": 500,
    "DC": 600,
    "DCC": 700,
    "DCCC": 800,
    "CM": 900,
}
tens = {
    "": 0,
    "X": 10,
    "XX": 20,
    "XXX": 30,
    "XL": 40,
    "L": 50,
    "LX": 60,
    "LXX": 70,
    "VXXX": 80,
    "XC": 90,
}
ones = {
    "": 0,
    "I": 1,
    "II": 2,
    "III": 3,
    "IV": 4,
    "V": 5,
    "VI": 6,
    "VII": 7,
    "VIII": 8,
    "IX": 9,
}


roman_numeral_dictionary = {}

for p in itertools.product(
    thousands.items(), hundreds.items(), tens.items(), ones.items()
):
    key = ""
    value = 0
    for symbol_value_pair in p:
        key += symbol_value_pair[0]
        value += symbol_value_pair[1]
    roman_numeral_dictionary[key] = value

roman_numeral_dictionary.pop("")

We define component dictionaries for each valid roman numeral that is purely a thousands, hundreds, tens or singles expression. Any valid expression is then given by the concatenation of the strings and addition of the values. The valid expressions are thus all possible pairings which is given by the cartesian product of all the dictionaries. (We add the empty string as a key to give a \(0\) value to represent not choosing from a given set)

Once we generated all the possible pairings we then build the dictionary by iterating over the pairings and concatenating the string components to create the string. The value is similarly created by adding all the value components.

Our actual implementation of the roman numeral lookup parser is simple, we normalise the input (convert to upper case and strip whitespace), and then simply try to get the value from the dictionary. As before we convert KeyError for missing values to ValueError to comply with the read_number interface

def roman_numeral_converter(number_string):
    """
    Convert a number written in roman numerals to an int

    The string must be a valid roman numeral in `standard format`__

    Parameters
    ----------
    number_string : str
        A valid roman numeral expression

    Returns
    -------
    int
        Result of converting the roman numeral to an int

    Raises
    ------
    ValueError
        Raised if `number_string` is not a valid roman numeral

    .. _standard format: https://en.wikipedia.org/wiki/Roman_numerals#Standard_form
    """
    try:
        return roman_numeral_dictionary[number_string.upper().strip()]
    except KeyError:
        raise ValueError("{0} is not a valid roman numeral".format(number_string))

If we wanted to make this even faster, we could have used a python program to generate the dictionary, print that out and copy the lookup table into the file. However for demonstration purposes seeing how it’s generated is useful

This implementation is found in RomanNumeralLookupTable.py and passes all the same tests as the previous one

Build Lists of Function References

  • Function references can be used as any other references
  • For example, we can create collections
# Example 12.3 Robot Dancer
#
# Demonstrates creating collections of function references

import time


def forward():
    print("Robot moving forward")
    time.sleep(1)


def back():
    print("Robot moving backwards")
    time.sleep(1)


def left():
    print("Robot moving left")
    time.sleep(1)


def right():
    print("robot moving right")
    time.sleep(1)


dance_moves = [forward, back, left, right]

print("Dance starting")
for move in dance_moves:
    move()
print("Dance over")
Dance starting
Robot moving forward
Robot moving backwards
Robot moving left
robot moving right
Dance over
  • We define a set of functions
  • Then create a collection referencing them
  • Here they represent a robot performing a sequence of dance moves
  • A longer program can then be created by increasing the length of the function

Use Lambda Expressions

  • A lambda function is like a tiny one line function
  • Has the following structure

block-beta
    columns 4
    space
    title["Breakdown of an Lambda Expression"]:2
    space

    block:LambdaStatement
    columns 1
        lambda["lambda"]
        lambdaDescr["(start of the lambda)"]
    end

    block:Arguments
    columns 1
        argument["arguments"]
        argumentDescr["(comma-separated list of arguments values)"]
    end

    block:Colon
    columns 1
        colon[":"]
        colonDescr["colon"]
    end

    block:Expression
    columns 1
        expression["expression"]
        expressionDescr["(expression to be evaluated)"]
    end

classDef BG stroke:transparent, fill:transparent
class title BG
class argument BG
class argumentDescr BG
class colon BG
class colonDescr BG
class lambda BG
class lambdaDescr BG
class expression BG
class expressionDescr BG

  • Colon separates arguments (supplied values) from expression (results coming out), e.g.
def increment(x):
    return x + 1
  • Is equivalent to,
increment = lambda x : x + 1
print(increment(1))
2
  • We can see this is called like a function, and returns the increment of the provided value
Make Something Happen: Make a Lambda Expression

Work through the following steps to understand lambda expressions

  1. Enter the following statement

     numbers = [1, 2, 3, 4, 5, 6, 7, 8]
    • This creates some sample data to work with
    • Let’s say we want to increment very value of numbers by \(1\)
    • We could do this normally by defining a function and using map
  2. Define a function increment as below, and run the following code

     def increment(x):
         return x + 1

     new_numbers = map(increment, numbers)
     print(list(new_numbers))
    [2, 3, 4, 5, 6, 7, 8, 9]
    • This works, but has two downsides
    • One have to name and define a function increment
    • The function then exists for the remaining lifetime of the scope
    • This is a natural use for a lambda
      • No need to associate a name
      • existence is restricted to the use of map
  3. Repeat the previous steps, but use a lambda as below instead of an explicit function

     new_numbers = map(lambda x : x + 1, numbers)
     print(list(new_numbers))
    [2, 3, 4, 5, 6, 7, 8, 9]
    • The same behaviour is observed
    • But the code is more compact, and the behaviour is localised to the map
  4. Create the following lambda

     adder = lambda x, y : x + y
    • addr is a lambda expression that takes two arguments and adds them
    • We can now use the lambda as we want
  5. Run the following expressions to demonstrate using the lambda

     adder(1, 2)
    3
    • We can see this evaluates like any other function call
Code Analysis: Lambda Expressions

Consider the following questions about lambda expressions

  1. What are lambda expressions?

    • Can think of them as data representing an operation to perform
    • Rather than passing a function reference we create a value containing that behaviour
    • lambda expressions are sometimes called anonymous functions
      • They are functional behaviour without a named handle
  2. Must I use lambda expressions in my programs?

    • No
    • Lambdas don’t add any new behaviour over defining functions
    • However, they can make code cleaner or more compact
    • They are especially useful for defining small temporary functions that are passed to things like map and filter
  3. Can a lambda function contain more than one action?

    • No
    • The active part of a lambda function is a single expression that calculates a return value
  4. Can a lambda expression accept multiple arguments?

    • Yes, we saw this with the addr lambda which took two arguments
    • Lambda’s can also technically take no arguments
  5. Can a lambda expression make decisions?

    • A lambda could return True or False

    • Can then use as a condition in programs

    • We can define conditional expressions to choose a value to return

        hour = 8
        print("morning" if hour < 12 else "afternoon")
      morning
    • Functions as an in line if statement

      • First value returned if condition evaluates true, else false

        block-beta
            columns 5
            space
            title["Breakdown of a Conditional Expression"]:3
            space

            block:ValueStatement
            columns 1
                value["value"]
                valueDescr["(value of expression if true)"]
            end

            block:If
            columns 1
                if["if"]
            end

            block:Condition
            columns 1
                condition["condition"]
                conditionDescr["(True or False condition)"]
            end

            block:Else
            columns 1
                else["else"]
            end

            block:Value2
            columns 1
                value2["value"]
                value2Descr["(value of expression if true)"]
            end

        classDef BG stroke:transparent, fill:transparent
        class title BG
        class value BG
        class valueDescr BG
        class if BG
        class else BG
        class colon BG
        class colonDescr BG
        class condition BG
        class conditionDescr BG
        class value2 BG
        class value2Descr BG

- Conditional expressions can be used anywhere an expression can be
- A lambda can thus return a conditional expression
    day_prompt = lambda hour : "morning" if hour < 12 else "afternoon"
    print("{0} is during the day: {1}".format(8, day_prompt(8)))
    print("{0} is during the day: {1}".format(13, day_prompt(13)))
8 is during the day: morning
13 is during the day: afternoon
Note

Don’t worry if you don’t get lambda expressions the first time you see them

Lambda expressions can be difficult to understand at first. They blur the lines between data and program code. Our previous programs seperate the data (as values) from the code (as functions). A lambda expression is code as data. Sometimes it’s useful to be able to pass behaviours around as data and lambdas provide a way to do that

Iterator Functions and the yield Statement

  • Recall python has a concept of an iterator

  • Generally when we encounter iterators we work through the values they generate

  • range is an example, e.g. creating a sequence of numbers

      for i in range(1, 5):
          print(i)
    1
    2
    3
    4
  • range returns a result that is an iterator producing the values \(1\) to \(4\).

  • When then consume the values to print them in order

    • Remember range does not include the end point
  • Iterators can be made by using the yield keyword

    • A yield is like a function return but the function remembers its state
    • functions that yield can be used to create a sequence of values
Make Something Happen: Investigating yield

Use an interpreter to work through the following steps to learn about the yield keyword

  1. Enter the following into the interpreter

     def my_yield():
         yield 1
         yield 2
         yield 3
         yield 4
    • The function my_yield contains four yield statements
    • Each returns a value
    • Let’s see what happens when we now loop over the function
  2. Define and run the following loop

     for i in my_yield():
         print(i)
    1
    2
    3
    4
    • We can see that the value returned by each yield is printed out in turn
    • We could also convert this to a list
  3. Define and run the following

     list(my_yield())
    [1, 2, 3, 4]
    • list accepts an iterator and converts it to list
Create a Test Data Generator using yield
  • yield can be used to make a flexible test data generator
    • e.g. for Time Tracker
    • e.g. If we want to do load testing for when we have hundreds of contacts rather than say tens
Tip

Using a program to create test data is a great idea

If you find yourself entering lots of test data into your programs, you should write a program to do the work for you. Remember that computers were created to spare us from drudgery, not create more of it

# Example 12.5 Test Contact Generator
#
# Demonstrates using yield to generate test Contacts for the
# time tracker application


class Contact:
    def __init__(self, name, address, telephone):
        self.name = name
        self.address = address
        self.telephone = telephone
        self.hours_worked = 0

    @staticmethod
    def create_test_contacts():
        phone_number = 1000000
        hours_worked = 0
        for first_name in ("Rob", "Mary", "Jenny", "Davis", "Chris", "Imogen"):
            for second_name in ("Miles", "Brown"):
                full_name = first_name + " " + second_name
                address = full_name + "'s house"
                telephone = str(phone_number)
                telephone = telephone + str(1)
                contact = Contact(full_name, address, telephone)
                contact.hours_worked = hours_worked
                hours_worked = hours_worked + 1
                yield contact
  • The test data generation is implemented as a static method
    • Let’s us access and set hidden attributes on the Contact class
  • Implementation (make_test_contacts) cycles through a set of first and last names
    • Contacts are then generated with a generated name, a simplified address (we simply append 's house' to the end of the name), a telephone number and hours_worked
    • Each iteration increases the telephone number and hours worked by one
  • We can the use the method as a iterator, see
for contact in Contact.create_test_contacts():
    print(contact.name)

contacts = list(Contact.create_test_contacts())

for contact in contacts:
    print(
        """{0}
Address: {1}
Telephone: {2}
Hours worked: {3}
""".format(contact.name, contact.address, contact.telephone, contact.hours_worked)
    )
Rob Miles
Rob Brown
Mary Miles
Mary Brown
Jenny Miles
Jenny Brown
Davis Miles
Davis Brown
Chris Miles
Chris Brown
Imogen Miles
Imogen Brown
Rob Miles
Address: Rob Miles's house
Telephone: 10000001
Hours worked: 0

Rob Brown
Address: Rob Brown's house
Telephone: 10000001
Hours worked: 1

Mary Miles
Address: Mary Miles's house
Telephone: 10000001
Hours worked: 2

Mary Brown
Address: Mary Brown's house
Telephone: 10000001
Hours worked: 3

Jenny Miles
Address: Jenny Miles's house
Telephone: 10000001
Hours worked: 4

Jenny Brown
Address: Jenny Brown's house
Telephone: 10000001
Hours worked: 5

Davis Miles
Address: Davis Miles's house
Telephone: 10000001
Hours worked: 6

Davis Brown
Address: Davis Brown's house
Telephone: 10000001
Hours worked: 7

Chris Miles
Address: Chris Miles's house
Telephone: 10000001
Hours worked: 8

Chris Brown
Address: Chris Brown's house
Telephone: 10000001
Hours worked: 9

Imogen Miles
Address: Imogen Miles's house
Telephone: 10000001
Hours worked: 10

Imogen Brown
Address: Imogen Brown's house
Telephone: 10000001
Hours worked: 11
Code Analysis: Using yield to Generate Test Contacts

Answer the following questions about the previous bits of code

  1. Why is create_test_contacts a static method?

    • We don’t want to ask a specific Contact for test information
    • We want to generate a new Contact as test data
    • Belongs with the Contact class itself
  2. What is the difference between yield and return?

    • yield pauses function execution and bookmarks where it is, returning the yield

      • Subsequent call follows on from this position
    • return returns the value and ends function execution

      • All subsequent executions will begin from the start of the function
    • return does not support iteration

    • Consider the following,

        def yield_return():
            yield 1
            yield 2
            return 3
            yield 4

        for i in yield_return():
            print(i)
      1
      2
    • The iteration only prints 1 and 2 since the third iteration encounters a return which ends the iteration (and is not included)

      • We never reach the yield 4 statement
  3. Does a function using yield have to return?

    • No

    • An iterator using yield could in theory run forever, e.g.

        def forever_tens():
            result = 0
            while True:
                yield result
                result = result + 10
    • This creates an infinitely long iteration

    • Each value is ten times larger than before

        for result in forever_tens():
            print(result)
            if result > 100:
                break
      0
      10
      20
      30
      40
      50
      60
      70
      80
      90
      100
      110
    • Loop continues until the result returned by the iterator is too large

  4. What happens to local variables in a yielded function?

    • Local variables are retained when the function yields a result
    • e.g. forever_tens() relies on the value of result being preserved between calls to generate the continuing sequence

Functions with an Arbitrary Number of Arguments

  • We’ve seen functions like print which seem to accept a variety of arguments, e.g.

      print("a")
      print("a", "b")
    a
    a b
  • When we’ve written functions, we’ve been able to define optional or default-valued parameters

  • However, we’ve always had to specify the number of variables

  • print accepts an arbitrary number of arguments

Make Something Happen: Investigating Arbitrary Arguments

Let’s learn about arbitrary-argument functions by working through the following steps in the interpreter

  1. Define the following function

     def add_function(x, y):
         return x + y
    • This is a function that adds two numbers

        add_function(1, 2)
      3
    • However if we tried to add three numbers,

        add_function(1, 2, 3)
      ---------------------------------------------------------------------------
      TypeError                                 Traceback (most recent call last)
      Cell In[28], line 1
      ----> 1 add_function(1, 2, 3)

      TypeError: add_function() takes 2 positional arguments but 3 were given
    • We see that we get an error because there’s a mismatch between the number of arguments required and supplied

  • It might make sense to have a function like add_function that accepts an arbitrary number of numbers and adds them all together

  • We can specify to a python function that an arbitrary number of arguments are accepted with the * identifier, e.g.

      def add_function(*values):
          total = 0
          for value in values:
              total = total + value
          return total
  • The above could accept any number of arguments, including zero

      print(add_function())
      print(add_function(1))
      print(add_function(1,2))
      print(add_function(1,2,3))
    0
    1
    3
    6
  • A parameter indicating an arbitrary number of parameters may be preceded by normal parameters

  • For example, if we wanted to force the add_function to receive at least one value

      def add_function(start, *values):
          total = start
          for value in values:
              total = total + value
          return total

      print(add_function(1))
      print(add_function(1,2))
    1
    3
  • If we try and pass nothing to the above, we get an error

          add_function()
    ---------------------------------------------------------------------------
    TypeError                                 Traceback (most recent call last)
    Cell In[32], line 1
    ----> 1 add_function()

    TypeError: add_function() missing 1 required positional argument: 'start'
  • What happens if the user already has an arbitrary number of values stored in a collection?

  • How do they translate a tuple say x = (1,2,3, 4) into the correct call structure?

    • Can’t just write add_function(x) since that will treat x as one variable
  • Need a way to unpack the contents

  • This is provided by the * operator

    • Unpacks a collection
  • For example,

      numbers = (1, 2, 3, 4)
      add_function(0, *numbers)
    10
  • Each element in numbers is unpacked out into their own argument

Warning

The * Character in function arguments can cause confusion with C and C++ syntax

As discussed in python * is used to represent unpacking a collection into it’s constituent values. Other languages may use * for different meanings. An example is C and C++ where * is used to handle and manipulate pointers (memory addresses). Something to learn as you work with multiple languages - be careful not to get your syntax’s confused.

  • Python provides an inbuilt function that performs the functionality of the add_function called sum
    • sum expects its arguments to passed as an iterable though
      sum(numbers)
    10
  • Some sample code for arbitrary argument functions is provided in ArbitaryArgumentFunctions.py

Modules and Packages

We’ve already seen that we can build python programs out of multiple source files. In this section we’ll look more closely at ways of structuring large python projects split across multiple files through the concepts of modules and packages

Python Modules

  • A python module is essentially a python file

  • For example the file BTCInput.py is a file that contains function definitions for reading valid input

    • We also call it a module
  • Typically the difference between a module and a script is that a module is designed to be imported by another program

    • A script typically runs standalone
    • This is just a heuristic though
  • We’ve seen that we can include a module using the import statement

  • So if we wanted to use BTCInput to read an integer restricted to a range, we write

      import BTCInput

      age = BTCInput.read_int_ranged(prompt="Enter age: ", min_value=5, max_value=95)
      print("Your age is: ", age)
  • A sample interaction might then be,

    Enter age:  31

    Your age is: 31

  • Python will execute and obey all statements in a module when a module is imported

  • For BTCInput these are function definitions

  • A module could also define variables or other code that should be executed on load-

Add a readme Function to BTCInput
  • We could add a readme function to BTCInput that describes the modules contents

      VERSION = "1.0.0"


      def readme():
          print(
              """Welcome to the BTCInput functions module version {0}

      BTCInput provides functions for reading numbers and strings and validating the
      user input.

      The functions are used as follows:
      text = read_text(prompt)
      int_value = read_int(prompt)
      int_float = read_float(prompt)
      int_value = read_int_ranged(prompt, min_value, max_value)
      float_value = read_float_ranged(prompt, min_value, max_value)

      BTCInput also provides read_number and read_number_ranged which can be
      used in conjunction with a user-defined function to provide custom
      number parsing behaviour

      Have fun with them.
      Rob Miles""".format(VERSION)
          )
  • readme displays a string which provides the user with some basic usage information

  • We’ve added a little variable that tracks the version of the file - automatically updated in the documentation

  • The user has to manually call the readme though

  • Later we’ll see how to generate the description text directly from the code docstring (View Program Documentation)

Run a Module as a Program
  • Python modules are files like any other
  • They can be run by the python interpreter
  • For example, we might add a call to readme
    • So someone running BTCInput automatically sees the documentation
      # all the BTCInput functions go here
      # end of the file
      readme()
    Welcome to the BTCInput functions module version 1.0.0

    BTCInput provides functions for reading numbers and strings and validating the
    user input.

    The functions are used as follows:
    text = read_text(prompt)
    int_value = read_int(prompt)
    int_float = read_float(prompt)
    int_value = read_int_ranged(prompt, min_value, max_value)
    float_value = read_float_ranged(prompt, min_value, max_value)

    BTCInput also provides read_number and read_number_ranged which can be
    used in conjunction with a user-defined function to provide custom
    number parsing behaviour

    Have fun with them.
    Rob Miles
  • Recall: on importing python executes all the statements in a file
  • This means the readme is displayed even when the user imports the module
    • Probably not the desired behaviour
Detect when a Module is Executed as a Program
  • Printing the readme is useful when the actual module is executed

  • However, would like a way to turn this off when the module is imported

  • Python provides the __name__ variable

    • Helps define the context in which the program is running
  • If a module is imported, __name__ is set to the name of the module

  • If a module is running as the original code that started the program, then __name__ is set to __main__

  • Can thus be used to restrict code that we don’t want to run outside of the __main__ context (or alternatively on import)

      if __name__ == "__main__":
          readme()
Make Something Happen: Checking Program Context

Click here to access the updated version of BTCInput

Run the file through the interpreter, you should see the readme be displayed. Then replace the implementation of BTCInput in one of the previous examples with this new implementation and run that program. You should see that the the readme will not be displayed even though the file is imported

  • Often useful to write modules also provide functionality as a program
  • For example, you may provide documentation as above, demonstrate examples alternatively a module may be designed to perform some basic functionality on user input (e.g. a mathematical program might read numbers and perform a calculation) and be imported by more complex programs

Create a Python Package

  • Large programs may contain many different program files
  • At that point we might want to start thinking about how we organise files, rather than have everything in one folder
  • This is the point at which packages can help
  • A common organisation pattern (that we’ve previously utilised) is to put every major component in it’s own file
  • For example in our Fashion Shop we created two types of classes
    1. Those that handled the data (StockItem, FashionShop)
    2. Those that handled the UI (FashionShopApplication)
  • Each of these components was written as it’s own file, and we wrapped the entry point in our FashionShopApplication.py
    • FashionShopApplication.py imported StockItem.py and FashionShop.py to get the associated class components
  • An alternative arrangement might be to formulate the data components as one package and the UI components as another
  • A (local) python package is a directory containing a set of python source files
    • An __init__.py file is used to mark a package
  • Below show’s how we could restructure the fashion shop application to use a package structure
.
├── Data
│   ├── FashionShop.py
│   ├── StockItem.py
│   └── __init__.py
├── FashionShopShellUI.py
└── UI
    ├── BTCInput.py
    ├── FashionShopApplication.py
    └── __init__.py
  1. UI contains the classes responsible for handling the user

    • Currently these are all shell-based

    • If in the future we introduce a GUI option we might create subpackages for UI

      1. ShellUI for shell-based interactivity
      2. GUI for graphical-based interactivity
    • Also contains an __init__.py file

  2. Data contains the classes responsible for handling the fashion shop data

    • This is the StockItem class, and the FashionShop container class
    • Again, we need the __init__.py
  3. Outside the class structure we define a FashionShopShellUI.py which is the entry point file

    • Consumes the classes in the subpackages
    • This is not a package itself, so no need for an __init__.py
Code Analysis: Making Modules

Consider the following questions about modules

  1. How do I decide which module goes in which package?

    • Related classes and functions should be in the same package

    • For the fashion shop as we’ve identified the types of modules are

      1. Those that handle the user interaction (FashionShopApplication.py and BTCInput.py)
      2. Those that handle the data representation of the fashion shop (FashionShop and StockItem)
  2. What does the __init__.py file in a package do?

    • __init__.py controls how a package is loaded
    • __init__.py is ran when a package is first opened
      • Like the constructor for a package
      • Can set up resources, e.g. a help string, global constants etc.

Import Modules from Packages

  • Modules can be imported from packages

    • Syntax is like that for importing a single class, function or variable from a module
      from Data import FashionShop
  • Contents of the FashionShop module now available

  • Can be used as we’ve seen before

      shop = FashionShop.FashionShop()
  • As we’ve talked before the FashionShop class is namespaced by the module FashionShop.py (minus the .py extension)

  • If there was another FashionShop defined in another package (say DataStorage.py) we can differentiate them, e.g.

      shop2 = DataStorage.FashionShop()
  • We could also just import the higher level package (Data) like a module, i.e.

      import Data
  • Contents of the Data package now available

    • Adds another level of namespacing, e.g. setting accessing the FashionShop class is now

        shop = Data.FashionShop.FashionShop()
Make Something Happen: Use Classes as Values

Classes can be used as values just as we’ve seen with functions. Work through the following steps in the python interpreter to understand how this works

  1. Enter the statements below into the python interpreter

     class VarTest:
         def __init__(self):
             print("making a VarTest")
    • This creates a class VarTest with a constructor

    • Constructor simply prints a message

    • We can create a VarTest instance easily enough

        x = VarTest()
      making a VarTest
    • We can see the __init__ method is called and we create a new VarTest instance, referenced by x

  2. Now assign the class definition itself to a variable, as in the statement below

     y = VarTest
    • Observe no parentheses around VarTest

    • Mirrors the case where we want a reference to a function

    • y has the value of VarTest which is the class definition itself

    • y is effectively an alias for VarTest and can be used the same way, e.g.

        z = y()
      making a VarTest
    • We can see that this creates a new VarTest instance and assigns it to z

      • As if we had written z = Vartest() directly
  • Class references can be treated as any other data, including

    1. Being used in collections (e.g. lists, dictionaries)
    2. Passed as arguments to function calls
  • The statement below sets the variable shop to the class definition of the FashionShop

      shop = FashionShop.FashionShop
  • Our UI shouldn’t need to know about the underlying data representation directly

    • Should just now the interface it needs to work with
    • Then we can have it accept any implementation that obeys this interface
    • We could say then pass shop as an argument
Code Analysis: References to Classes

Work through the following questions to understand how class references work

  1. What are the benefits of using class references?

    • Class references allow to define common implementations and then change the underlying implementation
      • We might replace the shell interface with a GUI
      • We might replace the FashionShop in-memory data storage with a database
    • If we can make the new implementations conform to the interface then all we need to do is change the class reference
      • Reduces the coupling between components
      • Makes the implementation easier to manage
  • How do we introduce class references in a program?

  • We’ll write a program FashionShopShellUI.py that handles connecting the components together

    • Creates the UI and displays it
    • Start by importing our modules
      # Example 12.8a Modular Fashion Shop
      #
      # Provides the entry point and coordinating behaviour for a modularised
      # implementation of the Fashion Shop Application


      from Data import FashionShop
      from UI import FashionShopApplication

      # load the UI implementation
      ui = FashionShopApplication.FashionShopApplication

      # load the data management implementation
      shop = FashionShop.FashionShop

      app = ui(filename="fashionshop.pickle", storage_class=shop)
  • We start by defining on ui and shop classes which take the UI implementation in FashionShopApplication and FashionShop respectively

  • We then have to create our application

    • We create an instance of the application (using the reference ui)
      • We pass shop to define how the data is managed
      • Observe that this is a new change to the API of FashionShopApplication we’ll have to implement
  • Let’s update the FashionShopApplication API

    • We want to accept a class reference now when we construct the object
    • So we have to add one to the __init__ method
    • We then want to replace explicit calls to FashionShop with calls to this class reference
      class FashionShopApplication:
          """
          Provides a text-based interface for Fashion Shop inventory management
          """
          def __init__(self, filename, storage_class):
              """
              Creates a new `FashionShopApplication`

              Attempts to load a `FashionShop` from the provided file. Otherwise
              an empty instance is created

              Parameters
              ----------
              filename : str
                  path to a file containing pickled `FashionShop` data
              storage_class : Data Manager
                  class that supports the Fashion Shop Data Management API

              See Also
              --------
              FashionShop : Main class for handling inventory management
              """
              FashionShopApplication.__filename = filename
              try:
                  self.__shop = storage_class.load(filename)
              except:  # noqa: E722
                  print("Failed to load Fashion Shop")
                  print("Creating an empty Fashion Shop")
                  self.__shop = storage_class()
    • We’ve changed the API on the __init__ so we have to make sure we update the docstring appropriately
  • Now we want to start running the program as before

      app.main_menu()
  • There is one small step as well which is to update the import statements in FashionShopApplication.py

    • No longer explicitly requires FashionShop

    • Needs to import StockItem from the Data package

    • Needs to import BTCInput from the UI package

        - import BTCInput
        + from UI import BTCInput
        - import StockItem
        + from Data import StockItem
        - import FashionShop
Warning

Python imports can be Confusing

An annoying feature of python import statements is that they are resolved relative to the directory where the entry point is. This means that even though BTCInput is in the same package as FashionShopApplication we can’t write

    import BTCInput

but instead have to write

    from UI import BTCInput

This is rather annoying because in theory FashionShopApplication shouldn’t need to care what folder it’s located in, let alone where the starting point is. If we wanted to write another higher level program that contained our entire fashion shop application as a package this would break the imports. The way to resolve this is to install the packages, but that’s beyond the scope for now

  • You can find the modularised implementation in 08_FashionShopApp
  • As an aside in the future as we add implementations we would likely rename FashionShopApplication to something more descriptive like FashionShopShell
Important

Using classes as values is an extremely powerful programming technique

The technique of passing functions or classes as arguments to higher-level classes or functions is called dependency injection. The idea is that if a class or function uses the interface of another class or function rather than hardcoding what the implementation of that interface is, we allow the implementation to be passed in as an argument (i.e. we inject the behaviour we want to implement)

The idea is to let us change how the behaviours specified by an API are implemented, for example we can use this to switch between a basic shell ui, a terminal-based ui or a full graphical ui. We might also want to switch our data storage layer from an in-memory approach to one that uses a database. If we hardcode the higher level implementation (i.e. a class that uses an in-memory loader and a shell ui) then we have to create many new implementations to support the desired behaviour. For example if we implement all the above options as hard coded classes we would have,

  1. in-memory loader + shell UI
  2. in-memory loader + terminal UI
  3. in-memory loader + graphical UI
  4. database loader + shell UI
  5. database loader + terminal UI
  6. database loader + graphical UI

In other words, we created three new classes (2 new UI classes and one data storage class) but then had to define five additional classes to handle creating our application. With dependency injection there is no need to define new classes, we just swap out what class references we are using and pass them through to the high level application constructor.

This design also makes it much easier to test large components because we can inject a test implementation.

Program Testing

  • Testing is part of the process of validating that a program meets requirements

  • Tests should be

    • Repeatable (we can conduct the same test multiple times)
    • Documented (they clearly indicate what they test and the results)
    • Automatic (tests should be an integrated part of development)
  • Let’s consider implementing tests for the StockItem from the Fashion Shop Application

  • We need to start by defining what features we want to test

    • Validate that newly constructed StockItem instances have correctly set values for their attributes
    • Attempts to create an invalid StockItem are rejected
    • StockItem methods behave as expected
  • We could start with manual testing

    • i.e. create a StockItem using the interpreter and check the behaviours
  • However this is clearly not automatic

  • It is difficult to repeat since we have to follow the steps clearly

  • Hard to document

    • Ideally the documentation should be colocated with the test
    • The same way we colocate documentation with a function (docstrings)
    • Clearly not the case if we’re manually entering values
  • Better is to write code that automatically tests the class

    • We’ve seen similar before where we’ve written print statements that output an expected versus actual value
    • See Roman Numeral Converter for an example
    • This still has the downside that we need to manually parse the output to check the tests passed
    • Would be good to automate this part of the process as well!
  • An improvement might be to use exceptions, e.g.

      item = StockItem(stock_ref="Test", price=10, tag="test:tag")
      if item.stock_level != 0:
          raise Exception("Initial Stock level not 0")
  • This means that any failed test will stop the program and alert the user

  • How could we test code that is supposed to throw an exception?

  • We could write a wrapper, e.g.

      excepted = False
      try:
          """
          Test behaviour that
          should raise an exception
          goes here
          """
      except: # ideally specify the exact exception we expect
          excepted = True

      if not excepted:
          raise Exception("Test Failed: No Exception raised")
  • Ideally define lots of small tests

  • Repeat the relevant tests each time part of a program is updated

  • On large programs tests might be run automatically every day, night etc.

  • Python provides some tools for making testing easier to implement

The Python assert Statement

  • Python defines the assert keyword

  • Let’s programs test as they run

  • Assert means “ensure this is true”

  • We can rewrite the previous test using assert

      item = StockItem(stock_ref="Test", price=10, tags="test:tag")
      assert item.stock_level == 0
  • Let’s see what happens if the assert fails

    • We’ll define a dummy StockItem class with a non-zero starting stock level
      class StockItem:
          def __init__(self, stock_ref, price, tags):
              self.stock_level = 1

      item = StockItem(stock_ref="Test", price=10, tags="test:tag")
      assert item.stock_level == 0
    ---------------------------------------------------------------------------
    AssertionError                            Traceback (most recent call last)
    Cell In[42], line 6
          3         self.stock_level = 1
          5 item = StockItem(stock_ref="Test", price=10, tags="test:tag")
    ----> 6 assert item.stock_level == 0

    AssertionError:
  • As we can see an AssertionError is raised

    • Just like any other form of exception
Code Analysis: Python Assertions

Work through the following questions about assert statements

  1. How many assert statements can a program contain?

    • There is no limit
  2. Does the program continue after an assertion has failed?

    • Depends on how the program handles it
    • If there’s no exception handling then the program will be stopped
    • A try...catch block may allow the program to recover

The Python unittest Module

  • assert lets us write checks that execute in code
    • Can be used to halt a program if an invalid state in encountered during execution
    • Doesn’t intrinsically help us write many, small, independent tests
  • Python provides a framework for automating the construction and execution of unit tests
  • Unit tests are small, self-contained test designed to verify one behaviour (a unit)
  • Unit tests for a component should be created alongside the component itself
    • In test-driven development the tests are written before the components themselves
      • Or at least defined until we stabilise the API
      • Code is written such that by implementing the behaviour to pass every more sophisticated tests we create a working component
  • unittest is provided as part of the python standard installation
    • Imported the usual way

        import unittest
  • Recall our complete (tag-based) StockItem implementation
class StockItem:
    """
    Represents a single inventory item

    Attributes
    ----------
    stock_ref : str
        reference id of the stock item
    tags : set[str]
        set of tags describing the stock item

    Class Attributes
    ----------------
    show_instrumentation : bool
        Indicates if instrumentation should be printed
    max_stock_add : int
        maximum amount of stock that can be added to an item's stock level at a time
    min_price : int | float
        minimum price of any stock item
    max_price : int | float
        maximum price of any stock item
    """

    show_instrumentation = True

    max_stock_add = 10

    min_price = 0.5
    max_price = 500

    def __init__(self, stock_ref, price, tags):
        """
        Creates a `StockItem` instance

        Parameters
        ----------
        stock_ref : str
            stock reference id
        price : int | float
            stock price
        tags : set[str]
            set of tags describing the stock item
        """
        if StockItem.show_instrumentation:
            print("**StockItem __init__ called")
        self.stock_ref = stock_ref
        self.__price = price
        self.tags = tags
        self.__stock_level = 0
        self.__StockItem_version = 4

    def __str__(self):
        if StockItem.show_instrumentation:
            print("**StockItem __str__ called")
        template = """Stock Reference: {0}
Price: {1}
Stock level: {2}
Tags: {3}"""
        return template.format(self.stock_ref, self.price, self.stock_level, self.tags)

    @property
    def price(self):
        """
        price : int | float
            dress price
        """
        if StockItem.show_instrumentation:
            print("**StockItem get price called")
        return self.__price

    @property
    def stock_level(self):
        """
        stock_level : int
            amount of stock in inventory
        """
        if StockItem.show_instrumentation:
            print("**StockItem get stock_level called")
        return self.__stock_level

    def check_version(self):
        """
        Checks the version of a `StockItem` instance and upgrades it if required

        Returns
        -------
        None
        """
        if StockItem.show_instrumentation:
            print("**StockItem check_version called")
        if self.__StockItem_version != 4:
            print("Stock item uses old data model, please recreate this item")

    def add_stock(self, count):
        """
        Add stock to an item

        Parameters
        ----------
        count : int
            amount of stock to add to an item

        Returns
        -------
        None

        Raises
        ------
        Exception
            raised if `count` < 0 or `count` > `StockItem.max_stock_add`

        See Also
        --------
        StockItem.max_stock_add : maximum amount of stock that can be added to a `StockItem`
        """
        if StockItem.show_instrumentation:
            print("**StockItem add_stock called")
        if count < 0 or count > StockItem.max_stock_add:
            raise Exception("Invalid add amount")
        self.__stock_level = self.__stock_level + count

    def sell_stock(self, count):
        """
        Sell stock of an item

        Decreases the item's stock level

        Parameters
        ----------
        count : int
            amount of stock to sell

        Returns
        -------
        None

        Raises
        ------
        Exception
            raised if `count` < 1 or `count` is greater than the available stock
        """
        if StockItem.show_instrumentation:
            print("**StockItem sell_stock called")
        if count < 1:
            raise Exception("Invalid number of items to sell")
        if count > self.__stock_level:
            raise Exception("Not enough stock to sell")
        self.__stock_level = self.__stock_level - count
  • Let’s use unittest to write some unit tests

  • unittest provides a class (TestCase) that acts as a superclass for tests

  • We create our tests by subclassing TestCase

    • We populate the class with method which implement our tests
  • First we’ll write a test for the initializer

      class TestStockItem(unittest.TestCase):

          def test_StockItem_init(self):
              item = StockItem(stock_ref="Test", price=10, tags="test:tag")
              self.assertEqual(item.stock_ref, "Test")
              self.assertEqual(item.price, 10)
              self.assertEqual(item.stock_level, 0)
              self.assertEqual(item.tags, "test:tag")
  • TestStockItem is our test class

    • The method test_StockItem_init tests the __init__ correctly sets the values on a StockItem instance
  • self.assertEqual is a method inherited from the TestCase superclass

    • Performs the test
    • Functions like an assert in that it checks that the value passed as the first argument matches the value in the second argument
      • If equal the test passes
      • Else, test fails
  • We can run the test by calling the main method for the unittest module

      unittest.main()
.
**StockItem __init__ called
**StockItem get price called
**StockItem get stock_level called

----------------------------------------------------------------------
Ran 1 test in 0.001s

OK
<unittest.main.TestProgram at 0x7f91a4897890>
  • The above should show that our test executed successfully
  • If we want more detail we can use the verbosity parameter
    • Integer number which represents the level of output detail
    unittest.main(verbosity=2)
test_StockItem_init (__main__.TestStockItem.test_StockItem_init) ... ok

----------------------------------------------------------------------
Ran 1 test in 0.001s

OK
**StockItem __init__ called
**StockItem get price called
**StockItem get stock_level called
<unittest.main.TestProgram at 0x7f91a4639010>
  • We can now see the name and status of each individual test
Warning

Attempting to run unittest in an IPython Notebook may cause issues

For IPython Notebooks such as the ones I have used to type up these notes, calling unittest.main() as written above fails to work due to intricacies with how the IPython works. The correct usage in that case is,

unittest.main(argv=['first-arg-is-ignored'], exit=False)

See Stack Overflow for an explanation

  • What happens if a test fails?

        class TestAlwaysFails(unittest.TestCase):

          def test_that_fails(self):
              self.assertEqual(1, 0)
  • The above defines a test that trivially fails, if we run our unit tests then

      unittest.main()
F.
======================================================================
FAIL: test_that_fails (__main__.TestAlwaysFails.test_that_fails)
----------------------------------------------------------------------
Traceback (most recent call last):
  File "/tmp/ipykernel_3198/3483629732.py", line 4, in test_that_fails
    self.assertEqual(1, 0)
AssertionError: 1 != 0

----------------------------------------------------------------------
Ran 2 tests in 0.001s

FAILED (failures=1)
**StockItem __init__ called
**StockItem get price called
**StockItem get stock_level called
<unittest.main.TestProgram at 0x7f91a47c1310>
  • The output indicates that tests have failed

  • Also specifies the specific failed test

  • There are a range of possible assertion conditions for statements

    • See the table below
Test Function Test Action Use Case
assertEqual(a,b) Asserts that a is the same as b Test that two values are the same
assertNotEqual(a, b) Asserts that a is not the same as b Test that two values differ
assertTrue(a) Asserts that a is True Test a boolean expression is true
assertFalse(b) Asserts that b is False Test a boolean expression is false
assertIs(a, b) Assert that a and b refer to the same object Test if two references (variables) refer to the same underlying memory object
assertIsNot(a, b) Assert that a and b refer to different objects Test two references refer to different memory objects
assertIsNone(a) Assert that r is None Test a variable is explicitly the None value
assertIsNotNone(a) Assert that a is not None Test a variable is explicitly not the None value
assertIn(a, b) Assert that a is in the collection b Test a value is in a collection
assertNotIn(a, b) Assert that a is not in the collection b Test a value is not in a collection
assertIsInstance(a, b) Assert that a is an instance of type b Test that a reference refers to an object of a specific type
assertNotIsInstance(a, b) Assert that a is not an instance of type b Test a reference does not refer to a particular object type
Test for Exceptions
  • The above table shows how we perform a value-based unit test
    • i.e we execute a statement and check it’s value or type against an expected result
  • What is want to perform a behaviour based unit test?
    • e.g. What if we want to test that code correctly throws an exception?
    • For example the code below attempts to add negative stock
      • Should raise an exception!
        item = StockItem(stock_ref="Test", price=10,  tags="test:tag")
        item.add_stock(-1)
  • We can use assertRaises to test for exceptions, e.g.
import unittest

class TestStockItem(unittest.TestCase):

    def test_StockItem_invalid_sell_stock_raises_exception(self):
        item = StockItem(stock_ref="Test", price=10, tags="test:tag")
        with self.assertRaises(Exception):
            item.add_stock(-1)
  • Running the unit test (hidden)
.
----------------------------------------------------------------------
Ran 1 test in 0.001s

OK
**StockItem __init__ called
**StockItem add_stock called
<unittest.main.TestProgram at 0x7f91a46398b0>
  • If we wanted to test for specific exceptions we can pass them to assertRaises as arguments
  • Note that assertRaises works slightly differently to the other tests
  • We have to wrap the functionality we want to test in the assertRaises context manager using the with keyword
    • assertRaises then attempts to catch the exception specified in it’s initializer
  • If the exception is not raised the test will fail

Create Tests

  • unittest makes it very easy to add tests to a project
  • Tests force you to think about how a component should behave
  • Tests might need you to clarify requirements with a client
    • e.g. We might ask our client to define a maximum amount of stock that could be added
      • Then implement a test to check that behaviour
  • First step is to test that an object is created correctly
  • After that can test specific behaviours
    • e.g. we want to test that the normal process of adding and selling stock works
      class TestStockItem(unittest.TestCase):

          def test_StockItem_add_and_sell_stock(self):
              item = StockItem(stock_ref="Test", price=10, tags="test:tag")
              self.assertEqual(item.stock_level, 0)
              item.add_stock(10)
              self.assertEqual(item.stock_level, 10)
              item.sell_stock(2)
              self.assertEqual(item.stock_level, 8)
  • Which should pass when run,
    unittest.main(verbosity=2)
test_StockItem_add_and_sell_stock (__main__.TestStockItem.test_StockItem_add_and_sell_stock) ... ok

----------------------------------------------------------------------
Ran 1 test in 0.001s

OK
**StockItem __init__ called
**StockItem get stock_level called
**StockItem add_stock called
**StockItem get stock_level called
**StockItem sell_stock called
**StockItem get stock_level called
<unittest.main.TestProgram at 0x7f91a48764e0>
Caution

Tests only prove the existence of faults

Tests are important and should always be included when making a program. Test’s do not guarantee that a program is correctly implemented, just that it passes the specific tests. It is typically impossible to test all possible paths through a program. Bugs can therefore exist even for extensive testing suites. You should form a habit of reviewing your code to ensure it works, alongside using automated testing to provide an additional layer of protection

Exercise: Complete the Testing of StockItem

The provided example tests, check only a limited portion of the StockItem functionality. First remove the automatically failing test, then implement additional tests to check more features of StockItem. For example, you should check that an exception is raised if sell_stock is passed a value greater than the current value of stock_level

We’ll try and implement a logical sequence of tests, such that each test, tests one functionality, and relies only on functionality that is tested by another test. In general we want to typically only have a single assert in a test, so that we can clearly identify the failure point. Let’s go through method by method

class TestStockItem(unittest.TestCase):
    def test_init(self):
        item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
        self.assertEqual(item.stock_ref, "Test")
        self.assertEqual(item.price, 10)
        self.assertEqual(item.stock_level, 0)
        self.assertEqual(item.tags, "test:tag")
  • We don’t need to modify this __init__ check, it checks all the attributes

    • Except the version, but this is a private variable so not easy to check
    • No methods let us interrogate the value
      • Not easy to test!
      • When things are hard to test, its generally a sign that they are not implemented in a very robust way
      • Right now version checking is a manual warning, but in future updates, we might seek to change this API to a more testable interface
  • Next we want to test the __str__ method

      def test_str(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          expected_str = """Stock Reference: Test
    Price: 10
    Stock level: 0
    Tags: test:tag"""
          self.assertEqual(str(item), expected_str)
    • We rely on the fact that __init__ has been tested
    • Then explicitly write out what the filled in string template should look like
    • Finally call assertEqual on the str(item) call, and then expected_str
  • Now lets test the add_stock method

  • There are three cases to consider here

    1. The normal case - stock is added as expected
    2. Trying to add more than the maximum - an exception is raised
    3. Trying to add negative stock - an exception is raised
  • Let’s implement these as three distinct tests

      def test_add_stock(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          item.add_stock(10)
          self.assertEqual(item.stock_level, 10)

      def test_add_stock_greater_than_maximum_raises_exception(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          with self.assertRaises(Exception):
              item.add_stock(StockItem.StockItem.max_stock_add + 1)

      def test_add_negative_stock_raises_exception(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          with self.assertRaises(Exception):
              item.add_stock(-1)
    • Each test checks one case
    • Makes each test small and easy to understand
    • Let’s us write long, descriptive names for all of them
  • Now lastly, we have to implement the corresponding checks for sell_stock

    1. Selling stock \(<\) current stock level and \(> 0\) - stock is reduced as expected
    2. Selling \(0\) stock - an exception is raised
    3. Selling negative stock - an exception is raised
    4. Selling stock \(>\) current stock level - an exception is raised
  • Again we’ll implement these as independent tests

        def test_sell_stock(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          item.add_stock(10)
          item.sell_stock(2)
          self.assertEqual(item.stock_level, 8)

      def test_sell_zero_stock_raises_exception(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          item.add_stock(10)
          with self.assertRaises(Exception):
              item.sell_stock(0)

      def test_sell_negative_stock_raises_exception(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          item.add_stock(10)
          with self.assertRaises(Exception):
              item.sell_stock(-1)

      def test_sell_stock_greater_than_stock_level_raises_exception(self):
          item = StockItem.StockItem(stock_ref="Test", price=10, tags="test:tag")
          with self.assertRaises(Exception):
              item.sell_stock(1)
    • These all follow a similar structure to those for add_stock
    • For test_sell_zero_stock_raises_exception and test_sell_negative_stock_raises_exception we use add_stock
      • add_stock is tested, so we know it won’t break these tests
      • Let’s us be sure that these tests fail because the specific scenario is violated and not because of a different overlapping fail case (e.g. selling more stock than we have)
  • We can then run these tests,

unittest.main(verbosity=2)
test_add_negative_stock_raises_exception (__main__.TestStockItem.test_add_negative_stock_raises_exception) ... ok
test_add_stock (__main__.TestStockItem.test_add_stock) ... ok
test_add_stock_greater_than_maximum_raises_exception (__main__.TestStockItem.test_add_stock_greater_than_maximum_raises_exception) ... ok
test_init (__main__.TestStockItem.test_init) ... ok
test_sell_negative_stock_raises_exception (__main__.TestStockItem.test_sell_negative_stock_raises_exception) ... ok
test_sell_stock (__main__.TestStockItem.test_sell_stock) ... ok
test_sell_stock_greater_than_stock_level_raises_exception (__main__.TestStockItem.test_sell_stock_greater_than_stock_level_raises_exception) ... ok
test_sell_zero_stock_raises_exception (__main__.TestStockItem.test_sell_zero_stock_raises_exception) ... ok
test_str (__main__.TestStockItem.test_str) ... ok

----------------------------------------------------------------------
Ran 9 tests in 0.007s

OK
<unittest.main.TestProgram at 0x7f91a47affb0>

Exercise: Refactoring Ride Selector to Support Testing

In Chapter 5 we designed the Ride Selector Program. When designing the UI, we considered how we would implement testing. Update the program to use unittest. You may need to refactor the code to introduce testability

The most recent version of Ride Selector is given as an exercise in Chapter 7 so we’ll use that version as our starting point.

As noted, the program as written is not amenable to testing. Everything is one big nested loop and the outputs printed directly to the terminal. We first need to refactor this program into one suitable for testing.

Let’s first start by defining a lightweight Ride class. Looking at our code we can see a ride has a name, and then optionally a maximum or minimum age. There is also a global minimum and maximum age limit.

class Ride:
    """
    A class representing a theme park amuse ride rider limitations

    Attributes
    ----------
    name : str
        name of the ride

    min_age : int
        minimum age in years to ride

    max_age : int
        maximum age in years to ride, must be greater than or equal to `min_age`

    Class Attributes
    ----------------
    ride_min_age : int
        minimum `min_age` for any ride

    ride_max_age : int
        maximum `max_age` for any ride

    """

    ride_min_age = 1
    ride_max_age = 95

    @staticmethod
    def is_valid_age_limit(age):
        """
        Check a proposed ride age limit is valid

        Parameters
        ----------
        age : int
            proposed age limit in years

        Returns
        -------
        bool
            `True` if `age` is an allowed age limit, else `False`

        See Also
        --------
        Ride.ride_min_age : minimum valid age limit for a ride
        Ride.ride_max_age : maximum valid age limit for a ride
        """
        return Ride.ride_min_age <= age <= Ride.ride_max_age

    def __init__(self, name, min_age, max_age):
        """
        Creates a new `Ride` instance

        Parameters
        ----------
        name : str
            name of the ride
        min_age : int
            minimum age (inclusive) to ride in years
        max_age : int
            maximum age to ride (inclusive) to ride in years.
            `max_age` must be `>= min_age`

        Raises
        ------
        ValueError
            Raised if `max_age` is `< min_age`
        ValueError
            Raised if `min_age` or `max_age` is not a valid age limit

        See Also
        --------
        Ride.is_valid_age_limit : Checks that ages are valid
        """
        if not Ride.is_valid_age_limit(min_age):
            raise ValueError(
                "{0} is not a valid age for the minimum age limit".format(min_age)
            )
        if not Ride.is_valid_age_limit(max_age):
            raise ValueError(
                "{0} is not a valid age for the maximum age limit".format(max_age)
            )
        if max_age < min_age:
            raise ValueError(
                "maximum age ({0}) must be greater than or equal to minimum age ({1})".format(
                    max_age, min_age
                )
            )
        self.name = name
        self.min_age = min_age
        self.max_age = max_age

    def __str__(self):
        return str(self.name)

    def in_age_limit(self, age):
        """
        Validate that an age is within the limits of the ride

        Parameters
        ----------
        age : int
            age in years to validate is within the age limit

        Returns
        -------
        bool
            `True` if the age is within the ride limits, else `False`
        """
        return self.min_age <= age <= self.max_age
  • The resulting class is lightweight

  • We define class variables ride_min_age and ride_max_age for the global minimum and maximum ages

  • We provide a function, is_age_valid_age_limit as a static method that checks a provided age is within these limits

    • Ride uses this internally to validate the min_age and max_age passed in __init__
    • Can also be used externally to check if an age is allowed on any ride
  • Defining our tests for is_age_valid_age_limit

      class TestRide(unittest.TestCase):
      """
      Test class implementing unit tests for the `Ride` class
      """

          # Test case for `is_valid_age_limit`

          def test_is_valid_age_accepts_normal_age(self):
              self.assertTrue(RideSelector.Ride.is_valid_age_limit(always_valid_middle_age))

          def test_is_valid_age_accepts_min_age(self):
              self.assertTrue(
                  RideSelector.Ride.is_valid_age_limit(RideSelector.Ride.ride_min_age)
              )

          def test_is_valid_age_accepts_max_age(self):
              self.assertTrue(
                  RideSelector.Ride.is_valid_age_limit(RideSelector.Ride.ride_max_age)
              )

          def test_is_valid_age_rejects_less_than_min_age(self):
              self.assertFalse(
                  RideSelector.Ride.is_valid_age_limit(RideSelector.Ride.ride_min_age - 1)
              )

          def test_is_valid_age_rejects_greater_than_max_age(self):
              self.assertFalse(
                  RideSelector.Ride.is_valid_age_limit(RideSelector.Ride.ride_max_age + 1)
              )
    • We can see there a range of test cases

      1. Test a standard value within the range is accepted
      2. Test the boundary values (ride_min_age and ride_max_age) are accepted
      3. Test values outside the boundaries are rejected
  • Next we can define our __init__ and __str__ methods

    def __init__(self, name, min_age, max_age):
        """
        Creates a new `Ride` instance

        Parameters
        ----------
        name : str
            name of the ride
        min_age : int
            minimum age (inclusive) to ride in years
        max_age : int
            maximum age to ride (inclusive) to ride in years.
            `max_age` must be `>= min_age`

        Raises
        ------
        ValueError
            Raised if `max_age` is `< min_age`
        ValueError
            Raised if `min_age` or `max_age` is not a valid age limit

        See Also
        --------
        Ride.is_valid_age_limit : Checks that ages are valid
        """
        if not Ride.is_valid_age_limit(min_age):
            raise ValueError(
                "{0} is not a valid age for the minimum age limit".format(min_age)
            )
        if not Ride.is_valid_age_limit(max_age):
            raise ValueError(
                "{0} is not a valid age for the maximum age limit".format(max_age)
            )
        if max_age < min_age:
            raise ValueError(
                "maximum age ({0}) must be greater than or equal to minimum age ({1})".format(
                    max_age, min_age
                )
            )
        self.name = name
        self.min_age = min_age
        self.max_age = max_age

    def __str__(self):
        return str(self.name)
  • The __init__ checks that the passed min_range and max_range are valid

    • Then checks that min_range and max_range follow the correct ordering
  • Once the input is validated just sets the appropriate data values

    • We’re leaving them public for the simplicity of demonstration
  • Our __str__ method is defined to simply return self.name as a string

  • We have a few tests here

    1. Test that we can construct an object normally and have the values set
    2. Test that an invalid min_age is rejected
    3. Test that an invalid max_age is rejected
    4. Test that min_age may not be greater than max_age
    5. Check that the appropriate string is returned
    # Test cases for init

    def test_init_sets_attributes_correctly(self):
        ride = RideSelector.Ride(
            "Test", min_age=always_valid_middle_age, max_age=always_valid_middle_age
        )
        self.assertEqual(ride.name, "Test")
        self.assertEqual(ride.min_age, always_valid_middle_age)
        self.assertEqual(ride.max_age, always_valid_middle_age)

    def test_init_raises_valueerror_on_invalid_min_age(self):
        with self.assertRaises(ValueError):
            ride = RideSelector.Ride(  # noqa: F841
                "Test",
                min_age=RideSelector.Ride.ride_min_age - 1,
                max_age=always_valid_middle_age,
            )

    def test_init_raises_valueerror_on_invalid_max_age(self):
        with self.assertRaises(ValueError):
            ride = RideSelector.Ride(  # noqa: F841
                "Test",
                min_age=always_valid_middle_age,
                max_age=RideSelector.Ride.ride_max_age + 1,
            )

    def test_init_raises_value_error_if_max_age_less_than_min_age(self):
        with self.assertRaises(ValueError):
            ride = RideSelector.Ride(  # noqa: F841
                "Test",
                min_age=RideSelector.Ride.ride_max_age + 1,
                max_age=RideSelector.Ride.ride_min_age - 1,
            )

    def test_str_returns_ride_name(self):
        ride = RideSelector.Ride(
            "Test",
            min_age=always_valid_middle_age,
            max_age=always_valid_middle_age,
        )
        self.assertEqual(str(ride), "Test")
  • The last method on Ride is one that now checks if a given age is accepted by the specific Ride instance
    def in_age_limit(self, age):
        """
        Validate that an age is within the limits of the ride

        Parameters
        ----------
        age : int
            age in years to validate is within the age limit

        Returns
        -------
        bool
            `True` if the age is within the ride limits, else `False`
        """
        return self.min_age <= age <= self.max_age
  • We pretty much want to test the same cases as for is_valid_age_limit

          def test_in_age_limit_accepts_valid_age(self):
          ride = RideSelector.Ride(
              "Test",
              min_age=always_valid_middle_age,
              max_age=always_valid_middle_age,
          )
          self.assertTrue(ride.in_age_limit(always_valid_middle_age))

      def test_in_age_limit_rejects_too_small_age(self):
          ride = RideSelector.Ride(
              "Test",
              min_age=always_valid_middle_age,
              max_age=always_valid_middle_age,
          )
          self.assertFalse(ride.in_age_limit(ride.min_age - 1))

      def test_in_age_limit_rejects_too_large_age(self):
          ride = RideSelector.Ride(
              "Test",
              min_age=always_valid_middle_age,
              max_age=always_valid_middle_age,
          )
          self.assertFalse(ride.in_age_limit(ride.max_age + 1))
  • Next we construct our RideSelector class

    • For simplicity this implementation mixes some of the container management aspects with the UI presentation aspects
    • Since some of the functionality requires user input or provides output to the user, we can’t test absolutely everything
    • Goal is to factor out the individual steps into functions that accept arguments and return values
    • These can then be tested against
  • RideSelector starts with a basic __init__ method that populates it with a preset lookup table of rides

  • The __str__ method converts the tuple of rides into an indexed list as a string

  • We’ll ignore testing the __init__ method for now

    • Since it’s not interesting
  • __str__ uses a quite complicated lambda though to perform it’s magic

    • The idea is to map the tuple elements to their enumerated pair
      • i.e. a tuple containing the index and the value
    • We then write use a lambda that maps the enumerated pair to the form x. value where x is the \(index + 1\) (since we want to convert from \(0\)-indexed to \(1\)-indexed) and value is the actual value
    • We then use map to apply the lambda to all elements of the enumerate object
    • Lastly convert into our string using "\n".join
    • This is quite a complicated set of steps and so should be tested
  • We’ll define a new test class for the RideSelector tests

    • This is to make them distinct
    • In a bigger program we would probably separate out each components tests into their own test file
    • Our __str__ test will take define an expected string and compare this to the result of calling the __str__ method
      class TestRideSelector(unittest.TestCase):
      """
      Test cases for the `RideSelector` class
      """

      # test str method
          def test_str_creates_enumerated_table(self):
              ride_selector = RideSelector.RideSelector()
              expected_str = """1. Scenic River Cruise
      2. Carnival Carousel
      3. Jungle Adventure Water Splash
      4. Downhill Mountain Run
      5. The Regurgitator"""
              self.assertEqual(str(ride_selector), expected_str)
  • Next we define a get_ride method that converts a user selection of a ride into the corresponding ride object

  • This has a simple implementation

          def get_ride(self, index):
          """
          Get's the ride associated with a given index

          Parameters
          ----------
          index : int
              integer greater than zero corresponding a ride index

          Returns
          -------
          Ride
              the ride stored by the given index

          Raises
          ------
          ValueError
              Raised if `index <= 0`
          IndexError
              Raised if the no ride exists for the given index
          """
          if index <= 0:
              raise ValueError("index must be a positive integer")
          return self._rides[index - 1]
  • There are clear cases to test here

    1. That a valid index returns the correct Ride instance
    2. That a non-positive index returns a ValueError
    3. That an invalid index returns an IndexError
      # test get_ride method

      def test_get_ride_returns_expected_ride(self):
          ride_selector = RideSelector.RideSelector()
          ride = ride_selector.get_ride(1)
          self.assertEqual(str(ride), "Scenic River Cruise")

      def test_get_ride_raises_valueerror_on_zero_index(self):
          ride_selector = RideSelector.RideSelector()

          with self.assertRaises(ValueError):
              ride_selector.get_ride(0)

      def test_get_ride_raises_valueerror_on_invalid_index(self):
          ride_selector = RideSelector.RideSelector()

          with self.assertRaises(IndexError):
              ride_selector.get_ride(99)
  • Our last testable component in then, check_age_against_ride

    • This takes in an age and a ride
    • Checks in a person of that age can ride the ride
    • This has two stages
      1. First validate that person can ride any ride
        • Using Ride.is_valid_age_limit
      2. Validate that person can ride the specific ride they selected
        • Using that ride’s in_age_limit method
    • Returns a string to display to the caller the outcome
      def check_age_against_ride(self, ride, age):
          """
          Provides a string describing in a rider of `age` years can ride the Ride `ride`

          Parameters
          ----------
          ride : Ride
              ride to check the age against
          age : int
              age of the prospective rider in years

          Returns
          -------
          str
              string describing if a rider of `age` years can ride `ride`
          """
          if age < Ride.ride_min_age:
              return "You are too young to go on any rides"
          elif age > Ride.ride_max_age:
              return "You are too old to go on any rides"
          elif age < ride.min_age:
              return "Sorry, you are too young"
          elif age > ride.max_age:
              return "Sorry, you are too old"
          else:
              return "You can go on the ride"
    • We want to test these strings are returned correctly

    • There are a few cases

      1. Too young to go on any ride
      2. Too young to go on this specific ride
      3. Too old to go on any ride
      4. Too old to go on this specific ride
      5. Able to go on the ride
    • Luckily since string literals are returned, we can check this easily

          # test check age against ride

      def test_too_young_for_any_ride(self):
          ride_selector = RideSelector.RideSelector()
          ride = ride_selector.get_ride(1)
          self.assertEqual(
              "You are too young to go on any rides",
              ride_selector.check_age_against_ride(
                  ride, RideSelector.Ride.ride_min_age - 1
              ),
          )

      def test_too_old_for_any_ride(self):
          ride_selector = RideSelector.RideSelector()
          ride = ride_selector.get_ride(1)
          self.assertEqual(
              "You are too old to go on any rides",
              ride_selector.check_age_against_ride(
                  ride, RideSelector.Ride.ride_max_age + 1
              ),
          )

      def test_too_young_for_specific_ride(self):
          ride_selector = RideSelector.RideSelector()
          ride = ride_selector.get_ride(5)
          self.assertEqual(
              "Sorry, you are too young",
              ride_selector.check_age_against_ride(ride, ride.min_age - 1),
          )

      def test_too_old_for_specific_ride(self):
          ride_selector = RideSelector.RideSelector()
          ride = ride_selector.get_ride(5)
          self.assertEqual(
              "Sorry, you are too old",
              ride_selector.check_age_against_ride(ride, ride.max_age + 1),
          )

      def test_valid_age_is_accepted(self):
          ride_selector = RideSelector.RideSelector()
          ride = ride_selector.get_ride(5)
          self.assertEqual(
              "You can go on the ride",
              ride_selector.check_age_against_ride(ride, ride.min_age),
          )
  • The last step is to the then run the tests

unitttest.main()
...............................
----------------------------------------------------------------------
Ran 31 tests in 0.028s

OK
<unittest.main.TestProgram at 0x7f91a47aec60>
Note

Be careful with how you design your tests

Tests are designed generally to test expected behaviours. This is why test-driven development typically expects you to write the test before the implementation. The idea being that by first defining the behaviour you want rather than testing a specific implementation you avoid coupling your test directly to your implementation.

This can be hard to avoid to some degree when dealing with unit tests because by their nature they test a specific unit. However, let’s look at our tests and some of the design choices. One of the main things I have done for some of the tests is to parameterise the values being tested, rather than hard-coding values. There is a trade-off here. The tests are a bit more opaque but are in theory flexible to changes. For example I have used the Ride.ride_min_age and Ride.ride_max_age points are:

  1. By using the values, we make the tests test the behaviour rather than the specific chosen values
  2. We couple the test to the implementation providing those class attributes
  3. If we change those values we might actually want the tests to fail, so that we can then manually ensure that the change is correct
    • Then update the test
    • However, this has the problem, that our test is then being dictated by the implementation
    • If we revert a change we would have to again rework the tests

The notion of using parameters versus specific-values is a choice in testing, the above is just an example of how to think about how to test. The other consideration is if the testing framework fits with the design of your program. In rewiring the ride selector program we’ve arguably made it more complex and harder to reason about by trying to fit it into the individual component model that unittest expects. For Ride Selector which provides a fairly simple user interface where we mostly care about the user receiving the correct response a better testing implementation might actually be to test the program externally. By this we mean, we generate a test set of inputs, feed them into the program and record the outputs. We then compare these outputs to the expected outputs.

Doing the testing this way has some tradeoffs. By testing the system as a whole it’s harder to identify where the sources of failures arise. However, the overall program doesn’t need to be refactored into a more complicated form just to facilitate the tests

View Program Documentation

  • We saw that you could add docstrings to functions to describe their behaviour
  • Implicitly in the examples you’ve also seen these added to classes
  • Modules can also have docstrings too!
    • The only rule across all three is that the docstring is the first statement after the start
      • i.e. for a function, after the function definition
      • for a class, after the class definition
      • for a module, the first statement in the file

Make Something Happen: Explore pydoc

Pydoc is a program written in python that can be run from the command line. Work through the following steps to see how it works

  1. Navigate to the folder 10_FashionShopWithDocumentation

  2. Open a terminal in this folder (or navigate to this folder in the terminal)

  3. Run the pydoc module, by executing the following command,

     python -m pydoc
    • The -m following the call to python means “execute the following module”

    • Running on pydoc with no additional arguments we can see it provides documentation about pydoc itself

        ! python -m pydoc
      pydoc - the Python documentation tool

      pydoc <name> ...
          Show text documentation on something.  <name> may be the name of a
          Python keyword, topic, function, module, or package, or a dotted
          reference to a class or function within a module or module in a
          package.  If <name> contains a '/', it is used as the path to a
          Python source file to document. If name is 'keywords', 'topics',
          or 'modules', a listing of these things is displayed.

      pydoc -k <keyword>
          Search for a keyword in the synopsis lines of all available modules.

      pydoc -n <hostname>
          Start an HTTP server with the given hostname (default: localhost).

      pydoc -p <port>
          Start an HTTP server on the given port on the local machine.  Port
          number 0 can be used to get an arbitrary unused port.

      pydoc -b
          Start an HTTP server on an arbitrary unused port and open a web browser
          to interactively browse documentation.  This option can be used in
          combination with -n and/or -p.

      pydoc -w <name> ...
          Write out the HTML documentation for a module to a file in the current
          directory.  If <name> contains a '/', it is treated as a filename; if
          it names a directory, documentation is written for all the contents.

    • We can see from the output that pydoc is a documentation tool

    • There a number of different arguments we can supply that modify how it runs

  4. For now we want to start a webpage to read our documentation. Reading the documentation we can see this can be done using the -b flag. Enter the following

     python -m pydoc -b
    • pydoc will then start a website that can be used to view the documentation

    • The result should look something like the screenshot below

      Generated Pydoc Website
    • We can see the site contains links to python’s built-in modules

    • But there is also a section for our own documented modules,

    • You can also use the built-in search bar

    • The docstrings are now displayed for the module, class and each method

Warning

Modules that run as programs can break pydoc

Recall that when loaded a module will execute all of the statements that it includes. For pydoc to generate the docstrings and site material from a module it first has to load it. This means that it will lead to those statements being executed.

This means that if we had a module that represented an entry point to looping user input (such as FashionShopShellUI.py) it would immediately start executing and freeze pydoc. This is a reminder to use name guards to control the context in which a module can be executed.

    if __name__ = "__main__":
        # do things that should only occur if the module is executed directly

Summary

  • We’ve seen that testing can be automated and integrated into a program
  • unittest is an in-built framework for performing unit testing
    • Unit tests are small tests that test a specific behaviour
  • Documentation is an important part of software development
    • Documentation can be added as docstrings to functions, classes and modules
    • Documentation can automatically be rendered
      • pydoc is an inbuilt python program for generating html sites of python documentation
  • Variables can refer to functions
    • Function references allow us to be flexible in implementing an interface
  • Lambda expressions allow us to write small expressions that apply actions to data
    • Lambda’s can also be treated as data themselves
  • yield allows us to write functions that serve as iterators
  • We can create packages in python
    • Packages organise and group up modules
  • Variables can refer to classes
    • Allows us to be flexible in implementation like with function references

Questions and Answers

  1. Is everything in python an object?

    • Yes
    • The advantage of python’s dynamic typing system is that everything is an object and can be treated as one
    • let’s us pass around a lot of different things to various parts of a system
      • Gives us lots of why to be flexible in implementation
    • The downside is that since there is no strict type checking we can get into situations where invalid objects are being passed
      • e.g. we might try to call a method on an int that it doesn’t possess
  2. Should I feel bad if I don’t understand things like lambda expressions and yield?

    • No
    • These are advanced and complicated features
    • It’s also natural for a concept to require repeated exposure and multiple passes to sink in
    • With simple programs you generally will not have a natural use for these features
      • When you do have those use cases though, they are powerful
  3. What happens when I move python packages from one computer to another?

    • They should work out of the box as long as a user has the correct version of python installed
    • If you mess with the directory structure you may need to update the packages
      • (See the comments about importing in packages made earlier)
    • A more permanent way is to publish a package, so that it can be installed (and preferably downloaded from the internet)
  4. When should I write my documentation and tests?

    • As you go along

    • There is a natural back and forth between documentation, tests and implementation

    • For a typical example workflow we might have a part of project we’re working on

      1. We start by documenting the design process
      2. We right some simple tests that we should aim to fulfill
      3. We then create an implementation
      4. We document the implementation as we go (preferably in code)
      5. We ensure the implementation passes the basic tests
      6. We add further tests to capture any unexpected behaviour found while implementing
    • Generally it is much easier to document a program as you write it and things are fresh than it is to go back and do it all

    • Same for tests

      • Write small bits of code then test them
      • Easier and more likely to result in a working program than writing one large block and a bunch of tests
      • Pythons dynamic typing and runtime error handling makes it very painful to try and fix large broken programs
